M-Tech Digital weighing indicator is a kind of weighing indicator specializing in digital truck scale application. It adopt technical platform of multi-task operation system. TFT display and all touch operation. It has digital advantage to a considerable degree and shows directly scale adjustment operation by graphical form and make it clear and high efficient; it reminds wrong operation and error by dialog and the descriptive instruction in the dialog make the error solution easy and precise It has the management interface for the clear weighing and suitable for static digital truck scale systems.
Main Features of D 39 Indicator:
- 7 inch 800x480 TFT color display
- High precise touch operation and quick reaction speed, no need for external keyboard support.
- Support Ethernet interface, RS232, RS232, RS485, Parallel printing interface and scoreboard interface.
- Various interface for digital scale adjustment and make full use of the digital function for truck scale.
- Abnormal Condition reminding with clear information and instruction for error solution.
- Support Chinese and English touch scoreboards input and make words editing easier.
- Various Scale analytic interface and make error solution easier.
- Support column load cells with angle test (Optimal)
- Multi-level management for user, maintenance people and manufacture
- Support routine C.E.K communication protocols.
- Isolated load cell with all external connection device in electrical part and the load cell has no influence the external electric leakage, the load cell interface of indicator has strong anti- surge and static protection.
- Type setting function for printing weighing note.
Main Technical Parameters:
- Digital load cell interface: RS485, total cable 75m if connections 12pcs load cells
- Transmission rate: 9600, 19200bps
- Power Supply: DC12V/750MA
- Load cells numbers: 1-16pcs
- Communication protocols: C protocol, C customized, E protocol, E Customized and K protocol
- Display Mode: 7inch800x480 TFT color display;
- Keyboard: Resistive touch screen
- Screen interface: 20mA current loop constant current serial output, Baud rate 600, transmission distances <100m
- Printer interface: Standard parallel printer interface, suitable with EPSON LQ -300K+ ll, EPSON LQ - 300K,EPSON LQ- 680K, EPSON LQ - 730K, EPSON LQ-1600K (+), KX- PII31, KX- PII21, POS58IV
- DS - 300 OR AB-300K
- Ethernet Interface: 10/100 Mbps
- Data Storage: 1000 Sets of tare, 4500 sets of new weighing Records,300 sets of new incomplete weighing
- Power Supply: Ac 110- 220V, 50-60HZ
- Dimension: 318x218x100mm
- Weight : Approx. 2.7 kg
